Choosing between a concealed and a visible hinge isn't just about looks, though that's usually where the decision starts. It also affects how a door adjusts over time, how it's installed, and how well it suits the overall style of your kitchen. This guide covers what genuinely separates the two, and gives a straightforward answer for which suits which kind of cabinet.
What's the actual difference between a concealed hinge and a visible hinge?
A concealed hinge sits entirely inside the cabinet, hidden between the door and the cabinet side when the door is closed, so nothing is visible from the outside at all. A visible hinge, sometimes called an exposed or surface-mounted hinge, sits on the outside of the door and cabinet frame, staying on show as part of the overall look rather than disappearing from view.
Why do most modern kitchens use concealed hinges?
Concealed hinges have become the default in most contemporary and frameless kitchens because they keep the door face completely clean, with nothing to interrupt a flat, minimal front. They're also genuinely adjustable once fitted, most concealed hinges let you fine-tune the door's position up, down, in, and out using two screws, which makes correcting a slightly misaligned door straightforward without removing anything. Our guide to cabinet hinges explained covers the full overlay, half overlay, and inset variations of concealed hinges in more detail, since the right type still depends on how your specific doors and cabinets are built.
When does a visible hinge actually suit a kitchen better?
Visible hinges genuinely work best in traditional, farmhouse, or period-style kitchens, where the hinge itself becomes part of the design rather than something to hide. A decorative brass or black butt hinge on a Shaker or in-frame door adds real character consistent with the style, in the same way a visible handle does, rather than looking like a compromise. If your kitchen leans traditional throughout, doors, worktops, and other ironmongery, a fully concealed hinge can occasionally look slightly out of place against everything else.
Does a concealed hinge cost more to fit than a visible one?
Not dramatically, though concealed hinges do require a cup hole to be drilled into the door, typically 26mm, 35mm, or 40mm depending on the hinge and door thickness, which needs reasonably precise drilling to sit correctly. Visible hinges are generally simpler to fit, screwed directly onto the surface without any recessed drilling, which is part of why they remain popular for smaller DIY projects and furniture restoration work.
Can I mix concealed and visible hinges in the same kitchen?
It's not common, and it's worth thinking carefully before doing it. Since concealed and visible hinges create such a different visual language, one hidden and minimal, the other decorative and on display, mixing them across the same run of cabinets tends to look inconsistent rather than deliberate. It's more usual to choose one approach for the whole kitchen and vary the finish or opening angle instead, our DTC 110° Hinge is available in both Anthracite and Nickel, for example, giving some flexibility in finish without changing the underlying hinge type.
What opening angle should I choose for a concealed hinge?
110° is the most widely used opening angle across UK kitchens, giving a comfortable, wide swing for general cabinet doors. Narrower cabinets, corner units, or doors near an appliance sometimes need a smaller angle instead, our 45° Small Overlay Hinge suits exactly this kind of tighter space, where a full 110° swing would cause the door to collide with something adjacent.
Frequently Asked Questions
1. Can you see a concealed hinge at all when the cabinet door is open?
Yes, once the door is open the hinge mechanism becomes visible inside the cabinet, it's only hidden when the door is closed, which is the opposite of how a visible hinge works.
2. Are concealed hinges harder to adjust than visible hinges if a door starts to sag?
No, concealed hinges are actually easier to fine-tune, most have two adjustment screws that let you shift the door up, down, in, or out without removing it, while a visible hinge usually needs to be unscrewed and repositioned to correct any sag.
3. What size cup hole do I need for a concealed hinge?
It depends on the hinge and door thickness, but 26mm, 35mm, and 40mm are the most common sizes, check your specific hinge's spec before drilling, since the wrong size hole won't seat the hinge cup correctly.
4. Do visible hinges suit a modern slab kitchen, or only traditional styles?
They're rarely used on a modern slab kitchen, since the clean, unbroken door face that style relies on works against having any visible hardware, visible hinges suit traditional, in-frame, or Shaker-style doors far better.
5. Is a concealed or visible hinge better for a heavy cabinet door?
Both can handle a heavy door if correctly specified, but it comes down to matching the specific hinge's weight rating to your door rather than the concealed-versus-visible choice alone, always check the manufacturer's stated capacity before fitting.
6. Why does my concealed hinge need a different opening angle for a corner cabinet?
A standard 110° hinge can cause the door to hit an adjacent cabinet or appliance in a tight corner, a smaller angle hinge, such as 45°, gives the door a shorter swing specifically to avoid that collision.
